Load Compensator For Height Adjustable Table
(57) Abstract
A table assembly comprising a leg assembly having upper and lower ends, the leg assembly including a fixed first member having upper and lower ends, a movable second member disposed in sliding engagement with the first member, the engagement including a retracted configuration and an expanded configuration, a cam member including a cam section, the cam member operably coupled to one of the first and second members, the cam member having a rotational range of travel from a first angular orientation corresponding to the expanded configuration of the first and second members to a second angular orientation corresponding to the contracted configuration of the first and second members, a spring supported by the leg assembly and operably coupled to the cam member, wherein the cam member and the spring cooperate to apply a force to the second member tending to drive the second member toward the expanded configuration, a velocity governor supported by at least one of the first and second members for, while the second member is moving, restricting the speed with which the second member moves with respect to the first member to a maximum speed without completely stopping second member.
